Name: JUKI DNU-1541 Single Needle Walking Foot Lockstitch Industrial Sewing Machine With Table and Servo Motor
Brand: JUKI
SKU: DNU-1541
Price: 1999.99 USD
Availability: InStock

JUKI DNU-1541 Single Needle Walking Foot Lockstitch Industrial Sewing Machine With Table and Servo Motor

SKU: DNU-1541

Weight: 1 lbs

Vendor: JUKI

Our Price: $1999.99 Market Price: $3200.00

Save: $1200.01 per unit

Assembled or Unassembled:

If assembled, ship to residential address:

If shipped to commercial address:

Upgrade to T-Leg Table w/ Wheels:

Head Only:

Please, enter quantity for at least one product

Quantity unavailable. Try selecting a smaller quantity.

Qty:


	New-Tech Automatic Bobbin Winder With Thread Stand		$49.99
	Synchronizer Needle Position Control For Industrial Sewing Machines		$44.99

JUKI DNU-1541

Single Needle Walking Foot Lockstitch Industrial Sewing Machine Comes With Table, Legs, Servo Motor and LED Lamp

With its larger needle bar stroke, higher presser foot lift, and newly adopted double-tension mechanism, the machine offers excellent sewing capabilities and responsiveness. The machine's rectangular feeding motion promises the consistent feeding of materials of all thicknesses without stitch gathering.

MACHINE SPECIFICATIONS:

Max. Sewing Speed: 2,500 Stitch per Minute
Max. Stitch Length: 9mm (forward / backward)
Needle Bar Stroke: 36mm
Lift of the Presser Foot by Hand: 9mm
Lift of the Presser Foot by Knee: 16mm
Thread Take-Up: Slide Type
Amount of Altering Vertical Movement: 2.5~6.5mm
Hook: Horizontal-Axis Full-Rotary Double-Capacity Hook
Needle (at time of delivery): 135x17 (Nm160) Nm125~Nm180
Bobbin Case: #18045
Bobbins: #18034
Thread: #30~#5, B46~B138, Nm=60/3~15/3
Pitch Changing Method: By Dial
Lubrication: Centralized Oil Wick Lubrication (hook: automatic)
Lubricating Oil: Juki New Defrix oil No.2 (equivalent to ISO VG32)
Distance from Needle to Machine Arm: 264mm
Bed Size: 477x178mm
Motor Output: 750W
Weight of the Machine Head: 36.5kg

DOWNLOADS:

U.S. WARRANTY

90 Days labor on defects in materials and workmanship.

** Head Only option does not include the table, legs, Servo Motor, and LED Lamp. No assembly or residential charges necessary.

DISCLAIMER: DUE TO THE WEIGHT AND SHIPPING METHODS USED FOR INDUSTRIAL MACHINES THEY MAY EXPERIENCE MARRING AND SCRATCHES DURING SHIPPING. THIS WILL NOT AFFECT THE OPERATION OF THE MACHINE.

THE ADVANTAGES OF A SERVO MOTOR:

They use up to 90% less power than clutch motors
They are 1/3 lighter than clutch motors
With a flick of the switch you can reverse motor rotation
No parts to wear out or adjust.
No matter how hard you press the foot pedal configured speed remains the same

Because of Servo motor speed control, most users find the machine is easier to use. Both beginning and seasoned sewers find this feature helpful when stitching projects that don't demand high-speed stitching.

ACCESSORIES for the JUKI DNU-1541

Needles: Sewing Machine Needles 135x17
Bobbins: Large "M" Style Bobbins #18034
Bobbin Case: Bobbin Case - Metal "M" Size #18045
Needle Plate: Needle Plate - JUKI #214-10006
Feed Dog: Feed Dog - JUKI #400-19908

PRESSER FOOT KIT
Walking Foot Presser Foot Kit - 18 Sets of Feet

OTHER ATTACHMENTS

BINDERS/FOLDERS
Raw Edge Binder Set #S64
Raw Edge Plain Tape Binder Binding Attachment #100LS
Right Angle Binder Set #S60
Double Fold Binder / Binding Attachment Folder #508L
Top Mount Collarette Binder Top Clean
Table Mount Coverstitch Collarette Binder #S124A

HEMMER
Single Fold Up Turn Hemmer #S75U

BUTTONHOLER
Buttonholer Attachment #YS-4455

RUFFLER
Deluxe Ruffler Attachment for Industrial Sewing Machines #G900E

GUIDES
Practical Suspended Edge Guide GB-6 - JUKI #MAH-15201-0A0
