New-Tech GC-8B Cylindrical Bed Compound Feed Lockstitch Industrial Sewing Machine With Table and Servo Motor
Product Pictures
This item is sold out
New-Tech GC-8B
Cylindrical Bed Compound Feed Lockstitch Industrial Sewing Machine Comes With Table, Legs, Servo Motor and LED Lamp
This standard size vertical hook walking foot (triple transport) cylinder bed machine is a new model with industry accepted features and styling. It features a sliding lever thread take up, a lever type stitch regulator and inside belt to drive the top shaft and hook shaft at high speed. It has a high presser foot lift thereby making it a capable piece of equipment in the construction of suitcases, soft-sided luggage, seat cushions, and binding operations on luggage, tote bags, and other similar article
MACHINE SPECIFICATIONS:
- Max Sewing Speed: 2200 rpm
- Stitch length: 0-5mm
- Needle bar stroke: 33.2mm
- Thread take-up lever stroke: 61.5mm
- Presser foot: lift By hand 8mm by knee 14mm
- Presser foot: Alternating walking presser foot
- Feed dog: Single row
- Needle Size: DP x 17 18#-22#
- Bed size in diameter: 62mm
- Rotating Hook
- Vertical hook
- Lubrication Manual
- Servo Motor
THE ADVANTAGES OF A SERVO MOTOR:
- They use up to 90% less power than clutch motors
- They are 1/3 lighter than clutch motors
- With a flick of the switch you can reverse motor rotation
- No parts to wear out or adjust.
- No matter how hard you press the foot pedal configured speed remains the same
Because of Servo motor speed control, most users find the machine is easier to use. Both beginning and seasoned sewers find this feature helpful when stitching projects that don't demand high-speed stitching.
