JUKI DDL-8700-H Heavy-Weight High-Speed Single Needle Straight Lockstitch Industrial Sewing Machine With Table and Servo Motor
JUKI DDL-8700-H Heavy-Weight High-Speed Single Needle Straight Lockstitch Industrial Sewing Machine With Table and Servo Motor
SKU:DDL-8700H
Juki DDL-8700-H Heavy-Weight High-Speed Single Needle Straight Lockstitch Industrial Sewing Machine With Table and Servo Motor
Couldn't load pickup availability

- Description
- Features
- Specifications
- Manuals & warranty
- More accessories
Heavy-Weight High-Speed Single Needle Straight Lockstitch Industrial Sewing Machine Comes With Table, Legs, Servo Motor and LED Lamp
By using the latest technology, the JUKI DDL-8700H has optimized the balance and rigidity of the machine head, providing the operator with a comfortable working environment by decreasing vibration and noise. Handling sewing material is easy because of the wide distance of the machine arm to the needle. Best of all this machine has all the desirable features of refined over generations of JUKI lockstitch machines.
Love Juki? Goldstar Tool Has You Covered
We carry several Juki machines, including the DDL-8700-H. Ready to move up to one of the world’s best machines? You can order right now from our website. Have questions? Call us at 1-800-868-4419 and we’ll be happy to answer everything for you.
MACHINE FEATURES:
The JUKI DDL-8700H's low tension sewing mechanism flexibly responds to a wide variety of fabrics and produces a beautiful seam with uniform quality.
- By thoroughly investigating and modifying the sewing mechanisms in order to achieve low-tension sewing, the machine flexibly responds to various kinds of materials and produces beautiful seams of consistent quality
Improved maintainability is guaranteed on the upgraded machine head.
- Enhanced maintainability is ensured by the improved machine head, such as incorporation of an eccentric pin that is used to adjust the feed dog. In addition, the machineis provided with a mounting seat for attachment to improve workability whilea replacing the attachment and increasing the durability of the machine bed surface.
Increase productivity with the presser foot with a higher lift, a light touch stitch dial and throat plate with marker groves to assist with seam allowance precision.
- By providing a presser foot with a higher lift(13mm), a lighttouch stitch dial, a throat plate with marker grooves that can be
- used as guide for seam allowance, and other easy-to-operate
- functions, the burden on the operator is lightened, and
- productivity is further increased.
MACHINE SPECIFICATIONS:
- Application: Heavy-Weight
- Max. sewing speed: 4,000 Stitches per Minute
- Max. stitch length: 5mm
- Needle bar stroke: 35mm
- Lift of the presser foot by hand: 5.5mm
- Lift of the presser foot: 13mm
- Needle (at the time of delivery): DB×1 (#21) #19~#23 134 (Nm130)
- Bobbin: #229-32909 (alternate part #270010)
- Feed dog: 3-row (3-row)
- Hook: Automatic-lubricating full-rotary hook
- Lubrication: Automatic
- Lubricating oil: JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
- Weight of the machine head: 28kg
DOWNLOADS:
- Instruction Manual - JUKI DDL-8700-H
- Catalog - JUKI DLL-8700-H
- Parts List - JUKI DDL-8700-H
- Caution For Safety - JUKI DDL-8700-H
- Setup Sheet - JUKI DDL-8700-H
U.S. WARRANTY:
90 Days labor on defects in materials and workmanship.
** Head Only option does not include the table, legs, Servo Motor, and LED Lamp. No assembly or residential charges necessary.
DISCLAIMER: DUE TO THE WEIGHT AND SHIPPING METHODS USED FOR INDUSTRIAL MACHINES THEY MAY EXPERIENCE MARRING AND SCRATCHES DURING SHIPPING. THIS WILL NOT AFFECT THE OPERATION OF THE MACHINE.
<h3><strong><u>ACCESSORIES for the JUKI DDL-8700H</u></strong></h3>
<div class="row"><div class="col-lg-6">
<p><strong>Oil: </strong><a href="https://www.goldstartool.com/juki-new-defrix-oil-no-1-mdfrx1600c0.htm" target="_blank">JUKI New Defrix Oil No. 1 #MDFRX1600C0</a><br><strong>Needles:</strong> <a href="https://www.goldstartool.com/standard-industrial-sewing-machine-needles.htm" target="_blank">Standard Industrial Needles (Size #9-#18)</a><br><strong>Bobbins:</strong> <a href="https://www.goldstartool.com/metal-bobbins-for-single-needle-industrial-industrial-sewing-machines-270010.htm" target="_blank">Metal Bobbins for Single Needle Industrial #270010</a><br><strong>Bobbin Case:</strong> <a href="https://www.goldstartool.com/bobbin-case-metal-class-95-52237.htm" target="_blank">Bobbin Case Metal Class 95 — Singer #52237</a><br><strong>Needle Plate:</strong> <a href="https://www.goldstartool.com/needle-plate-throat-plate-for-most-single-needle-industrial-sewing-machines.htm" target="_blank">Needle Plate /Throat Plate</a><br><strong>Needle Plate/Feed Dog Combo:</strong> <a href="https://www.goldstartool.com/needle-plate-throat-plate-feed-dog-for-most-industrial-lockstitch-sewing-machines-combo.htm" target="_blank">Needle Plate/Feed Dog Combo</a><a href="https://www.goldstartool.com/needle-plate-throat-plate-feed-dog-for-most-industrial-lockstitch-sewing-machines-combo.htm" target="_blank"></a><a href="https://www.goldstartool.com/needle-plate-throat-plate-feed-dog-for-most-industrial-lockstitch-sewing-machines-combo.htm" target="_blank"><br><br></a></p>
<p><strong><strong><em><em>ACCESSORY KITS</em></em></strong><br></strong><a href="https://www.goldstartool.com/starter-kit-for-industrial-sewing-machines.htm" target="_blank">Starter Kit For Industrial Sewing Machines<br></a><a href="https://www.goldstartool.com/deluxe-spare-parts-kit-for-industrial-lockstitch-sewing-machines.htm" target="_blank">Deluxe Kit For Industrial Sewing Machines</a></p>
<p><strong><em>PRESSER FOOT KITS</em></strong><br><a href="https://www.goldstartool.com/5-pack-industrial-high-shank-presser-feet.htm" target="_blank">5 Pack Industrial High Shank Presser Feet</a><br><a href="https://www.goldstartool.com/glide-on-industrial-high-shank-presser-feet-5-pack.htm" target="_blank">Glide-On Industrial High Shank Presser Feet (5 Pack)</a><br>
</p>
<p><em><strong>SEWING GUIDES & GAUGES</strong></em><a href="https://www.goldstartool.com/magnetic-sewing-machine-gauge.htm" target="_blank"><br></a><a href="https://www.goldstartool.com/magnetic-sewing-machine-gauge.htm" target="_blank">Magnetic Sewing Machine Gauge Guide</a><br><a href="https://www.goldstartool.com/quilters-swing-sewing-guide-for-industrial-sewing-machines.htm" target="_blank">Quilters Swing Sewing Guide</a><br><a href="https://www.goldstartool.com/industrial-sewing-machine-swing-gauge-5812.htm" target="_blank">Swing Gauge #5812</a><a href="https://www.goldstartool.com/sewing-machinest-gauge-2-1-2.htm" target="_blank"><br>T Gauge (2-1/2")</a><a href="https://www.goldstartool.com/adjustable-seam-guide-sewing-adjustable-seam-guide-for-industrial-single-needle-sewing-machine.htm" target="_blank"><br>Adjustable Seam Guide</a><a href="https://www.goldstartool.com/sewing-machine-3-corner-gauge-25873.htm" target="_blank"><br>Sewing Machine 3 Corner Gauge #25873</a></p><h3><strong><br></strong></h3><h3><strong>COMPATIBLE PRESSER FOOT OPTIONS</strong></h3>
<p><strong><em>ZIPPER/CORDING/WELTING/PIPING<br></em></strong><a href="https://www.goldstartool.com/invisible-zipper-presser-foot-s518.htm" target="_blank">Invisible Zipper Presser Foot #S518<br></a><a href="https://www.goldstartool.com/split-hinged-zipper-presser-foot-40322sh.htm" target="_blank">Split Hinged Zipper Presser Foot #40322SH<br></a><a href="https://www.goldstartool.com/narrow-right-hinged-cording-foot-for-industrial-lockstitch-sewing-machines-12435hn.htm" target="_blank">Narrow Right Hinged Cording Foot #12435HN<br></a><a href="https://www.goldstartool.com/narrow-left-hinged-cording-foot-for-industrial-lockstitch-sewing-machines-31358hn.htm" target="_blank">Narrow Left Hinged Cording Foot #31358HN<br></a><a href="https://www.goldstartool.com/wide-left-hinged-cording-zipper-foot-31358hwl-p36l.htm" target="_blank">Wide Left Hinged Cording/Zipper Foot #31358HWL-P36L<br></a><a href="https://www.goldstartool.com/wide-right-hinged-cordingzipper-foot-12435hwr-p36r.htm" target="_blank">Wide Right Hinged Cording/Zipper Foot #12435HWR-P36<br></a><a href="https://www.goldstartool.com/high-shank-double-welting-piping-foot-for-industrial-single-needle-sewing-machines-36069dg.htm" target="_blank">High Shank Double Welting/Piping Foot #36069DG<br></a><a href="https://www.goldstartool.com/metal-piping-foot-high-shank-right-or-left.htm" target="_blank">Metal Piping Foot (Right Or Left) #36069L, 36069R<br></a><a href="https://www.goldstartool.com/welting-piping-cording-presser-foot-767415000-767414009.htm" target="_blank">Welting/Piping/Cording Presser Foot #767415000</a></p>
<p><strong><em>COMPENSATING<br></em></strong><a href="https://www.goldstartool.com/left-compensating-presser-foot-for-industrial-sewing-machines.htm" target="_blank">Left Compensating Presser Foot<br></a><a href="https://www.goldstartool.com/right-compensating-presser-foot-for-industrial-sewing-machines.htm" target="_blank">Right Compensating Presser Foot<br></a><a href="https://www.goldstartool.com/compensating-binder-presser-foot-for-industrial-sewing-machines.htm" target="_blank">Compensating Binder Presser Foot<br></a><a href="https://www.goldstartool.com/compensating-foot-211-14.htm" target="_blank">Compensating Foot 211-14</a></p>
<p><strong><em>SHIRRING/GATHERING<br></em></strong><a href="https://www.goldstartool.com/shirring-gathering-foot-for-industrial-lockstitch-sewing-machines.htm" target="_blank">Shirring/Gathering Foot #120828<br></a><a href="https://www.goldstartool.com/shirring-gathering-with-adjustable-blocks-for-industrial-lockstitch-sewing-machines-s950.htm" target="_blank">Shirring/Gathering With Adjustable Blocks #S950<br></a><a href="https://www.goldstartool.com/shirring-gathering-screw-adjusting-presser-foot-s952.htm" target="_blank">Shirring/Gathering Screw Adjusting Presser Foot #S952<br></a><a href="https://www.goldstartool.com/shirring-gathering-tape-guide-elastic-adjustable-presser-foot-for-industrial-sewing-machines-s537.htm" target="_blank">Shirring/Gathering Tape Guide Elastic Adjustable Presser Foot #S537</a></p>
<p><strong><em>GUIDE FOOT<br></em></strong><a href="https://www.goldstartool.com/industrial-sewing-machine-hinged-right-guide-foot.htm" target="_blank">Hinged Right Guide Foot</a></p>
<p><em><strong>BUTTONHOLE FOOT</strong></em><br><a href="https://www.goldstartool.com/high-shank-buttonhole-foot.htm" target="_blank">High Shank Buttonhole #CY-703H</a><em><strong></strong></em><em><strong><br></strong></em><em><strong><br></strong></em></p></div>
<div class="col-lg-6">
<strong></strong><h3><strong>COMPATIBLE PRESSER FOOT OPTIONS (continued)</strong></h3>
<p><strong><em>HEMMER</em></strong><br><a href="https://www.goldstartool.com/shirring-gathering-with-adjustable-blocks-for-industrial-lockstitch-sewing-machines-s950.htm" target="_blank">Ball Hemmer Foot (Double Fold) #490358<br></a><a href="https://www.goldstartool.com/spring-hemmer-feet-high-shank.htm" target="_blank">Spring Hemmer Foot #490359<br></a><a href="https://www.goldstartool.com/hemming-presser-foot-and-folder-set-f502.htm" target="_blank">Hemming Presser Foot and Folder Set #F502</a></p>
<p><strong><em>CENTER TUBE</em></strong><br><a href="https://www.goldstartool.com/hinged-center-tube-presser-foot-for-industrial-sewing-machine.htm" target="_blank">Hinged Center Tube Presser Foot #S10C</a></p>
<p><strong><em>ROLLER<br></em></strong><a href="https://www.goldstartool.com/small-roller-foot-with-needle-plate-feed-dogs-singer.htm" target="_blank">Small Roller Foot With Needle Plate & Feed Dogs<br></a><a href="https://www.goldstartool.com/large-roller-foot-with-needle-plate-feed-dogs-singer.htm" target="_blank">Large Roller Foot With Needle Plate & Feed Dogs<br></a><a href="https://www.goldstartool.com/spk-high-shank-roller-foot-spk3.htm" target="_blank">SPK Roller Foot #SPK3</a></p>
<p><strong><em>BIAS<br></em></strong><a href="https://www.goldstartool.com/bias-tape-binding-presser-foot-6288.htm" target="_blank">Bias Tape Binding Presser Foot #6288</a></p>
<p><strong><em>STRAIGHT STITCH<br></em></strong><a href="https://www.goldstartool.com/hinged-straight-stitch-presser-foot-p351.htm" target="_blank">Hinged Straight Stitch Presser Foot #P351<br></a><a href="https://www.goldstartool.com/hinged-straight-stitching-foot-24983.htm" target="_blank">Hinged Straight Stitching Foot #24983<br></a><a href="https://www.goldstartool.com/hinged-narrow-presser-foot-for-industrial-sewing-machines.htm" target="_blank">Hinged Narrow Presser Foot #142058N<br></a><a href="https://www.goldstartool.com/heavyweight-straight-stitch-presser-foot-brother-sa173.htm" target="_blank">Heavyweight Straight Stitch Presser Foot - Brother #SA173<br></a><a href="https://www.goldstartool.com/straight-stitch-presser-foot-with-finger-guard-351.htm" target="_blank">Straight Stitch Presser Foot With Finger Guard #351</a></p>
<p><strong><em>GLIDE-ON/TEFLON<br></em></strong><a href="https://www.goldstartool.com/glide-on-invisible-zipper-presser-foot-s518nst.htm" target="_blank">Glide-On Invisible Zipper Presser Foot #S518NST<br></a><a href="https://www.goldstartool.com/glide-on-standard-extended-tail-hinged-presser-foot-mt-18.htm" target="_blank">Glide-On Standard Extended Tail Hinged Presser Foot #MT-18<br></a><a href="https://www.goldstartool.com/glide-on-welting-piping-cording-presser-foot-36069t.htm" target="_blank">Glide-On Welting/Piping/Cording Presser Foot #36069T<br></a><a href="https://www.goldstartool.com/non-stickteflon-foot-high-shank.htm" target="_blank">Non-Stick Glide-On Presser Foot #T-350<br></a><a href="https://www.goldstartool.com/universal-glide-on-narrow-zipper-presser-foot-t363.htm" target="_blank">Universal Glide-On Hinged Narrow Zipper Presser Foot #T-363<br></a><a href="https://www.goldstartool.com/universial-glide-on-left-narrow-zipper-presser-foot-t36ln.htm" target="_blank">Universal Glide-On Left Narrow Zipper Presser Foot #T36LN<br></a><a href="https://www.goldstartool.com/universal-glide-on-right-narrow-zipper-presser-foot-t36n.htm" target="_blank">Universal Glide-On Right Narrow Zipper Presser Foot #T36N</a></p>
<p><strong><em>FOR QUILTING<br></em></strong><a href="https://www.goldstartool.com/quilters-swing-sewing-guide-for-industrial-sewing-machines.htm" target="_blank">Quilters Swing Sewing Guide For Industrial Sewing Machines<br></a><a href="https://www.goldstartool.com/1-4-inch-high-shank-clear-ruler-foot-for-free-motion-quilting.htm" target="_blank">1/4" High Shank Clear Ruler Foot For Free Motion Quilting</a><a href="https://www.goldstartool.com/1-4-high-shank-ruler-foot-for-free-motion-frame-quilting-sewing.htm" target="_blank"><br>1/4" High Shank Metal Ruler Foot For Free Motion Quilting</a><br><a href="https://www.goldstartool.com/metal-quilting-glide-foot-and-needle-plate-gs1kit.htm" target="_blank">Metal Quilting Glide Foot and Needle Plate #GS1Kit</a><br><br></p>
<h3>OTHER ATTACHMENTS</h3>
<p><em><strong>BINDERS/FOLDERS</strong><a href="https://www.goldstartool.com/raw-edge-binder-set-s64.htm" target="_blank"><br></a></em><a href="https://www.goldstartool.com/raw-edge-binder-set-s64.htm" target="_blank">Raw Edge Binder Set #S64</a><a href="https://www.goldstartool.com/raw-edge-plain-tape-binder-binding-attachment-100ls.htm" target="_blank"><br>Raw Edge Plain Tape Binder Binding Attachment #100LS</a><a href="https://www.goldstartool.com/right-angle-binder-set-s60.htm" target="_blank"><br>Right Angle Binder Set #S60</a><br><a href="https://www.goldstartool.com/double-fold-binder-binding-attachment-folder-508l.htm" target="_blank">Double Fold Binder / Binding Attachment Folder #508L</a><a href="https://www.goldstartool.com/collarette-binder-top-mount-1864.htm" target="_blank"><br>Top Mount Collarette Binder Top Clean</a><br></p>
<p><strong><em>BUTTONHOLER</em></strong><a href="https://www.goldstartool.com/buttonholer-attachment-ys-4455.htm" target="_blank"><br>Buttonholer Attachment #YS-4455</a></p>
<p><strong><em>RUFFLER</em></strong><a href="https://www.goldstartool.com/deluxe-ruffler-attachment-for-industrial-sewing-machines-g900e.htm" target="_blank"><br>Deluxe Ruffler Attachment for Industrial Sewing Machines #G900E</a></p>
<p><a href="https://www.goldstartool.com/ball-hemmer-foot-double-fold-high-shank-no490358-choose-size.htm" target="_blank"></a></p>
</div>
</div>
ACCESSORIES for the JUKI DDL-8700H
Oil: JUKI New Defrix Oil No. 1 #MDFRX1600C0
Needles: Standard Industrial Needles (Size #9-#18)
Bobbins: Metal Bobbins for Single Needle Industrial #270010
Bobbin Case: Bobbin Case Metal Class 95 — Singer #52237
Needle Plate: Needle Plate /Throat Plate
Needle Plate/Feed Dog Combo: Needle Plate/Feed Dog Combo
ACCESSORY KITS
Starter Kit For Industrial Sewing Machines
Deluxe Kit For Industrial Sewing Machines
PRESSER FOOT KITS
5 Pack Industrial High Shank Presser Feet
Glide-On Industrial High Shank Presser Feet (5 Pack)
SEWING GUIDES & GAUGES
Magnetic Sewing Machine Gauge Guide
Sewing Machine 3 Corner Gauge #25873
COMPATIBLE PRESSER FOOT OPTIONS
ZIPPER/CORDING/WELTING/PIPING
Invisible Zipper Presser Foot #S518
Split Hinged Zipper Presser Foot #40322SH
Narrow Right Hinged Cording Foot #12435HN
Narrow Left Hinged Cording Foot #31358HN
Wide Left Hinged Cording/Zipper Foot #31358HWL-P36L
Wide Right Hinged Cording/Zipper Foot #12435HWR-P36
High Shank Double Welting/Piping Foot #36069DG
Metal Piping Foot (Right Or Left) #36069L, 36069R
Welting/Piping/Cording Presser Foot #767415000
COMPENSATING
Left Compensating Presser Foot
Right Compensating Presser Foot
Compensating Binder Presser Foot
SHIRRING/GATHERING
Shirring/Gathering Foot #120828
Shirring/Gathering With Adjustable Blocks #S950
Shirring/Gathering Screw Adjusting Presser Foot #S952
Shirring/Gathering Tape Guide Elastic Adjustable Presser Foot #S537
GUIDE FOOT
BUTTONHOLE FOOT
High Shank Buttonhole #CY-703H
COMPATIBLE PRESSER FOOT OPTIONS (continued)
HEMMER
Ball Hemmer Foot (Double Fold) #490358
Hemming Presser Foot and Folder Set #F502
CENTER TUBE
Hinged Center Tube Presser Foot #S10C
ROLLER
Small Roller Foot With Needle Plate & Feed Dogs
Large Roller Foot With Needle Plate & Feed Dogs
BIAS
Bias Tape Binding Presser Foot #6288
STRAIGHT STITCH
Hinged Straight Stitch Presser Foot #P351
Hinged Straight Stitching Foot #24983
Hinged Narrow Presser Foot #142058N
Heavyweight Straight Stitch Presser Foot - Brother #SA173
Straight Stitch Presser Foot With Finger Guard #351
GLIDE-ON/TEFLON
Glide-On Invisible Zipper Presser Foot #S518NST
Glide-On Standard Extended Tail Hinged Presser Foot #MT-18
Glide-On Welting/Piping/Cording Presser Foot #36069T
Non-Stick Glide-On Presser Foot #T-350
Universal Glide-On Hinged Narrow Zipper Presser Foot #T-363
Universal Glide-On Left Narrow Zipper Presser Foot #T36LN
Universal Glide-On Right Narrow Zipper Presser Foot #T36N
FOR QUILTING
Quilters Swing Sewing Guide For Industrial Sewing Machines
1/4" High Shank Clear Ruler Foot For Free Motion Quilting
1/4" High Shank Metal Ruler Foot For Free Motion Quilting
Metal Quilting Glide Foot and Needle Plate #GS1Kit
OTHER ATTACHMENTS
BINDERS/FOLDERS
Raw Edge Plain Tape Binder Binding Attachment #100LS
Double Fold Binder / Binding Attachment Folder #508L
Top Mount Collarette Binder Top Clean
BUTTONHOLER
Buttonholer Attachment #YS-4455
RUFFLER
Deluxe Ruffler Attachment for Industrial Sewing Machines #G900E
JUKI DDL-8700 FAQs
What kind of needles do you use in the DDL-8700?
The needles with your JUKI are the Organ DBx1, available on our website. This machine uses size 16×257, size 8 through 20 or 16×97. The 8700 can also use standard needles, sizes 9 through 21, universal or fabric-specific needles such as knit.
Where does the machine oil go?
A pan directly underneath the machine supplies oil to the machine with a cotton wick. Lift the machine up and over to access the oil tank while on the table. You must keep the machine’s oil level consistently at the «high» mark, either by adding more oil or draining it and refilling it as needed. If the oil pump can’t get the oil into the machine, it can cause serious problems later.
What kind of oil does this machine require?
You need a specific type, like motor oil in your car, to keep this machine running. The DDL-8700 requires JUKI New Defrix Oil No.1, equivalent to ISO VG7.
What size table can I get with this machine?
Our table has legs and is 22"w x 47"l. It includes a knee and foot pedals and a left-hand drawer for accessories.
Does the DDL 8700 make buttonholes?
No. The 8700 only does straight stitching, with a horizontal bar on the right side for a reverse stitch.
