JUKI LG-158 Series Long-arm Unison-feed Lockstitch Machine With Vertical-axis Large Hook With Table and Servo Motor
JUKI LG-158 Series Long-arm  Unison-feed Lockstitch Machine With Vertical-axis Large Hook With Table and Servo Motor
reseller raitng
Product Videos

JUKI LG-158 Series Long-arm Unison-feed Lockstitch Machine With Vertical-axis Large Hook With Table and Servo Motor

SKU: LG-158 Series
Weight: 1 lbs
Vendor: JUKI
Our Price: $13499.99
There will be a surcharge of $150 if shipped to a residential address
Please, enter quantity for at least one product
Quantity unavailable. Try selecting a smaller quantity.

JUKI LG-158 Series

Long-arm, Unison-feed, Lockstitch Machine with Vertical-axis Large Hook With Table, Legs, Servo Motor, and LED Lamp

Love JUKI? Goldstar Tool Has You Covered

We carry several JUKI machines, including the DDL-8700. Ready to move up to one of the world’s best machines? You can order right now from our website. Have questions? Call us at 1-800-868-4419, and we’ll be happy to answer everything for you.

About the JUKI LG-158 Series

With its 750 mm wide space under the arm and a handwheel mounted at the
middle of the arm, the machine is ideal for sewing heavy
materials such as tents and sheets. A large material can be sewn while
spread over the bed.
The bobbin winder is installed at the front face of the arm for easy
operation.
The presser foot goes up as high as 21.5 mm to ensure easy
placement/removal of extra heavy-weight materials.

Ideal for the sewing of heavy materials such as tents and sheets.

MACHINE FEATURES:

  • The machine head structure is designed to improve the operability
  • Safety device protects the needle and hook from damage
  • Consistent seam quality
  • The frequency of bobbin thread replacement is reduced

MACHINE SPECIFICATIONS:

  • Max. Sewing Speed: 1500 sti/min
  • Max. Stitch Length: 10mm (forward/reverse feed)
  • Needle Bar Stroke: 46.9mm
  • Needle Gauge:
    • LG-158: Standard 19.1mm (3/4")
    • LG-158-1: -----
  • Lift of Presser Foot:
    • By Pedal: 21.5mm
  • Thread Take-up: Side Type
  • Alternating Vertical Movement:  6~19mm
  • Hook: Vertical-axis large hook
  • Needle at Time of Delivery: DD×1 (#25)
  • Thread: #20#5, B69B138, Nm=40/320/3
  • Safety Mechanism: Provided as standard
  • Bobbin Winder: Built on the machine arm
  • Lubrication: By an oiler
  • Lubricating Oil: JUKI New Oil No.1 (equivalent to ISO VG7)
  • Distance from needle to machine arm: 750mm
  • Bed Size: 1,088mm×230mm
  • Weight of the machine head: 108kg

DOWNLOADS:

U.S. WARRANTY:

90 Days labor on defects in materials and workmanship.

** Head Only option does not include the table, legs, Servo Motor, and LED Lamp. No assembly or residential charges necessary.

DISCLAIMER: DUE TO THE WEIGHT AND SHIPPING METHODS USED FOR INDUSTRIAL MACHINES THEY MAY EXPERIENCE MARRING AND SCRATCHES DURING SHIPPING. THIS WILL NOT AFFECT THE OPERATION OF THE MACHINE.

THE ADVANTAGES OF A SERVO MOTOR:

  • They use up to 90% less power than clutch motors
  • They are 1/3 lighter than clutch motors
  • With a flick of the switch you can reverse motor rotation
  • No parts to wear out or adjust.
  • No matter how hard you press the foot pedal configured speed remains the same

Because of Servo motor speed control, most users find the machine is easier to use. Both beginning and seasoned sewers find this feature helpful when stitching projects that don't demand high-speed stitching.
