Name: Yamata FY335A Triple Feed Walking Foot Lockstitch Cylinder Arm Industrial Sewing Machine With Table and Servo Motor
Brand: Yamata
SKU: FY335A
Price: 1399.99 USD
Availability: InStock

Yamata FY335A Triple Feed Walking Foot Lockstitch Cylinder Arm Industrial Sewing Machine With Table and Servo Motor

Our Price: $1399.99

Market Price: $1800.00

Choose Color

Choose Options

Assembled or Unassembled:

If assembled, ship to residential address:

If shipped to commercial address:

Upgrade to T-Leg Table w/ Wheels:

Head Only:

About the Yamata FY335A

The FY335A is a Medium to Heavy Duty Walking Foot Cylinder Bed with Compound Needle Feed or (Unison Feed) Lockstitch Sewing Machine with an “M” size Big Bobbin and end of the cylinder Big Size Rotating Hook mechanism.

The FY335A machine includes a lever-operated stitch length mechanism with a reverse feed regulator for back tacking and stitching in reverse. Some additional features of the FY335A include a semi-automatic lubrication system. The machine sews thread from size z-46 up to size z-207 in the needle with up to z-138 in the bobbin.

MACHINE FEATURES:

50mm diameter Large horizontal axis rotary hook reduces the frequency of bobbin change
Semi-automatic lubrication system
Simple wing nut adjustment permits raising and lowering of the center foot to allow for sewing different thicknesses of material.
It is developed for hemming shoes, purses, belts, sewing bags, sofas, and shaping sport apparatus.

MACHINE SPECIFICATIONS:

Sew up to: 7/16"
Thread Size: Up to 207 / Reverse feed
Speed, Max (SPM): 2500
Presser Foot Lift by Hand: 5/16" (8mm)
Presser Foot Lift by Foot: 1/2" (13mm)
Needle: 135x17, DPx17 Needles System
Stitch Length Max: @4.2 SPI (6mm)
Cylinder Diameter: 1-31/32" (50mm)
Work Space: 10-5/32" x 4-11/32" (258mm x 110mm)

U.S. WARRANTY:

90 Days labor on defects in materials and workmanship.

** Head Only option does not include the table, legs, Servo Motor, and LED Lamp. No assembly or residential charges necessary.

DISCLAIMER: DUE TO THE WEIGHT AND SHIPPING METHODS USED FOR INDUSTRIAL MACHINES THEY MAY EXPERIENCE MARRING AND SCRATCHES DURING SHIPPING. THIS WILL NOT AFFECT THE OPERATION OF THE MACHINE.

THE ADVANTAGES OF A SERVO MOTOR:

They use up to 90% less power than clutch motors
They are 1/3 lighter than clutch motors
With a flick of the switch, you can reverse motor rotation
No parts to wear out or adjust.
No matter how hard you press the foot pedal configured speed remains the same

Because of Servo motor speed control, most users find the machine is easier to use. Both beginning and seasoned sewers find this feature helpful when stitching projects that don't demand high-speed stitching.

Yamata FY335A Triple Feed Walking Foot Lockstitch Cylinder Arm Industrial Sewing Machine With Table and Servo Motor
